Rigging work
12.6 Outriggers
Operating manual GMK 6400 3 112 993 en 12 - 33
12.07.2013
12.6.4 Preparing the truck crane
In the driver's cab Levelling the truck crane
• Align the truck crane horizontally with the level adjustment system;
à Operating the level adjustment system, p. 5 - 60.
Locking the suspension
• Switch off the suspension; à p. 5 - 14.
The operating elements for the outriggers are only released if the suspen-
sion is switched off. If the suspension is switched off, the wheels are lifted
when the crane is put on outriggers.
Outriggers control
units
You can switch the
Outrigger control units on and off from the crane cab.
• If necessary, open the main menu ö and press the (1) button once.
This opens the
Settings submenu.
The current status is displayed:
– Symbol (2) – operating units on, buttons
enabled
– Symbol (3) – operating units off, buttons dis-
abled
• To switch on or off, press the button next to
the symbol (1) once.
