Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual GMK 6400 3 112 993 en 9 - 59
12.07.2013
9.2.3 Engine
Side panel à Start the engine, p. 10 - 8.
Ignition lock
Carrier ignition indicator lamp
Setting idling speed
– The engine is off::
– The engine is running
:
Flame start system indicator lamp
s
–0 Ignition off, engine off, key can be removed
–R, 1 Ignition on and power supply on for:
instrument lighting, ECOS, engine control system, RCL
–2 Starting position
à p. 10 - 5
–On: Ignition in driver's cab on,
engine start not possible
– Off: Ignition in driver's cab off,
engine start possible
à p. 10 - 8
– Press down 1 x: Engine starts,
idling speed = standard
– Press down: Increase idling speed
– Press up: Decrease idling speed,
after about 6 seconds: engine stop
à p. 10 - 12
–On: Engine not ready to start – warming up
– Off: Engine is ready to start
à p. 10 - 9
