Driving modes and rigging for on-road driving
6.5 Installing/removing the supporting box
6 - 70 3 112 993 en Operating manual GMK 6400
12.07.2013
6.5.10 Slinging points on the supporting box
At the top of the outrigger box there are two
slinging points (1).
Use only these slinging points for fastening
the lifting gear.
G
Risk of accident if used improperly
Attach the outrigger box only to the designated points and only use lifting
gear of sufficient lifting capacity. Weight of the outrigger box;
à Dimensions and weights of removable parts, p. 1 - 10.
