Rigging work
12.10 Other rigging work
Operating manual GMK 6400 3 112 993 en 12 - 135
12.07.2013
12.10 Other rigging work
12.10.1 Railings on the turntable
Always fold the railings out when you are standing on the counterweight or
the auxiliary hoist to perform rigging work.
You must also observe the railing notice on the auxiliary hoist;
à p. 12 - 106.
(A) – Folding out
• Release the locking bar (2) and swing the
railing (1) outward until it engages.
(B) – Folding in
• Release the locking bar (2) and swing the
railing (1) inward until it engages.
G
Risk of accidents when railings are not folded out!
The railings provide protection from falling. Always fold out the railings
before moving onto the auxiliary hoist.
