Starting/turning off the engine for driving
4.1 Starting the engine from the driver's cab
4 - 20 3 112 993 en Operating manual GMK 6400
12.07.2013
Indicator lamps on
the instrument
panel
Several lamps must go out on the instrument panel when the engine is run-
ning.
• Check that the lamps (1) and (2) go out.
If one or both lamps are lit, refer to the information in section
Right after
starting
; Ã p. 5 - 37.
Lamp (3) only goes out when the vehicle starts moving.
• Stop the engine immediately if one of the lamps (1) is lit.
• Check that the lamp (1) goes out.
– When the lamp (1) lights up:
The main menu shows a symbol.
– If the lamp (1) flashes:
The steering angle of the 5th and 6th axle line does not relate correctly to
the 1st to 2nd axle line.
• Steer using the steering wheel – the steering angle is automatically off-
set, and the lamp (1) goes out.
With the sym-
bol (2):
The oil supply for the steering is still being built up. If
the symbol has not yet gone out, contact Manitowoc
Crane Care
With the sym-
bol (3):
Service mode on.
Briefly turn off the ignition and then on again. If the
symbol is still not shown, contact Manitowoc Crane
Care.
With the sym-
bol (4):
The 5th and 6th axle lines are brought into the straight
running position, as far as is possible, and can no
longer be steered.
It is possible to steer the 1st to 2nd axle lines.
Arrange for the error to be rectified.
