Driving modes and rigging for on-road driving
6.4 Installing/removing outrigger beams
Operating manual GMK 6400 3 112 993 en 6 - 37
12.07.2013
6. Sling the outrigger beam and pull it out of the outrigger box until it
reaches the centre of gravity;
à p. 6 - 47.
7. – Sling the outrigger beams in the centre of gravity and pull them out
of the outrigger box.
– Lift the outrigger beams onto the separate vehicle.
– Attach the connecting elements on the outrigger box.
à Extending outrigger beam, p. 6 - 47
à Transporting the outrigger beams, p. 6 - 51
8. Remove all necessary outrigger beams in the same way in accordance
with this checklist.
