Overview
1.5 Technical data
1 - 18 3 112 993 en Operating manual GMK 6400
12.07.2013
Derricking gear
Main boom
Lattice extension As additional equipment;
à Lattice extension operating instructions.
Operating speeds The specified operating speeds only apply to an engine speed of about
2000 rpm without load.
Cylinder: Differential cylinder
Adjusting angle
(main boom):
–1.5° to + 83° from horizontal position
Power unit group: M2 (in accordance with ISO 4301 - 2)
Main boom lengths: 15.4 m to 60.0 m (50.5 ft to 196.9 ft)
Main boom head: 7 sheaves
10 sheaves
1)
Cylinder: One single-level telescoping cylinder with
locking/unlocking mechanism
Power unit group:
Telescoping mechanism:
M 1 (in accordance with ISO 4301 - 2)
1)
Additional equipment
Main hoist: Rope speed when lifting and lowering
Normal speed: maximum 63 m/min (207 ft/min)
High-speed mode: maximum 126 m/min (413 ft/min)
Auxiliary hoist: Rope speed when lifting and lowering
Normal speed: maximum 63 m/min (207 ft/min)
High-speed mode: maximum 126 m/min (413 ft/min)
Slewing gear: 0 to 1.3 revolutions per minute
Telescoping
mechanism:
Extending from 15.4 to 60.0 m (50.5 to 196.9 ft)
approx. 740 s In automatic mode during uninter-
rupted locking and telescoping
processes
Derricking gear: Derricking between –1.5° and 83°
Normal speed: To raise: approx. 130 s
High-speed mode: To raise: approx. 95 s
