Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual GMK 6400 3 112 993 en 9 - 75
12.07.2013
Hoist high-speed mode on/off
The parking brake must be engaged.
High speed indicator lamp for hoists
Warning for lifting limit switch shutdown
–Left: High-speed mode on, off when released
– 1 x to right: High-speed mode on – continuous operation
– 1 x to right or 1 x to left: High-speed mode off
à p. 11 - 97
–On: High-speed mode on
– Off: High-speed mode off
à p. 11 - 97
–On: Lifting limit switch triggered – hoist stops
– Flashing: Lifting limit switch triggered – shutdown overridden
– Off: Lifting limit switch not triggered
à p. 11 - 62
