1.7 Notes on the operating instructions
Operating manual GMK 6400 3 112 993 en 1 - 27
12.07.2013
The parking brake is used as an example to show how the cross-references guide
you through the operating instructions.
A In this example, the general overview is shown on page 4 - 2.
The driver's cab is labelled as number 1. The related table contains a
cross-reference in the form
1Driver's cab
à p. 4 - 4
B Page 4 - 4 shows a top view of the driver's cab.
The parking brake is labelled as number 2. The related table contains a
cross-reference in the form
2 Parking brake
à p. 4 - 37
C Page 4 - 37 gives a brief description of all the functions of the parking
brake.
If further information is available, the brief description contains a
cross-reference, e.g.
4 Test posi-
tion for tow-
ing a trailer:
– Pull the lever down until it locks into place
– Press in the lever and pull it further backwards
The parking brake for the trailer is released;
à p. 6 - 82.
D Follow the cross-reference to page 6 - 82. Here, the test position of the
parking brake when towing a trailer is described in detail, with all the
preliminary requirements and safety instructions.
There may be additional cross-references here, such as to related
pages in the chapter
Malfunctions.
