Crane operation
11.2 Operation of the rated capacity limiter
11 - 44 3 112 993 en Operating manual GMK 6400
12.07.2013
Raising after RCL shutdown
You can re-enable raising with the switch (1) in order to leave the shutdown
range.
The speed will then be reduced to 50%.
Requirement
– The engine for crane operation is running.
Raising the main boom
• Press the (1) button up once.
– Raising is enabled.
The RCL will show an information code;
à p. 11 - 48.
– The status display will flash green.
• Raise the main boom with the control lever until the degree of utilisation
is less than 100%.
The crane movements will then be enabled again.
H
The raising of the main boom will be shut down if the main boom angle is
too great. Then all you can do is set the load down.
If the degree of utilisation is over 100%, you can cancel the function by:
– Pressing switch (1) up again,
– Switching off the ignition.
