Rigging work
12.7 Rigging/unrigging the counterweight
12 - 90 3 112 993 en Operating manual GMK 6400
12.07.2013
Rigged outrigger span 8.70 x (28.5 x)
7.98 x (26.1
x)
2.71 m
(8.9 ft)
5.00 m
(16.4 ft)
6.30 m
(20.4 ft)
7.40 m
(24.3 ft)
8.50 m
27.9 ft)
8.50 m
(27.9 ft)
1.00 m
(3.3 ft)
(auxiliary
support)
1)
Rigged counterweight
0 t
(0 lbs)
15 t
(33 069 lbs)
35 t
(77 162 lbs)
55 t
(121 254 lbs)
Slewing
permissible
1)
Slewing
not per-
missible
75 t
(165 347 lbs)
95 t
(209 439 lbs)
Slewing
not per-
missible
115 t
(253 532 lbs)
135 t
(297 624 lbs)
1)
Outrigger span for removable outrigger box
2)
Slewing only permitted if the radius permitted in the working range is
observed (at least 3.0 m [9.8 ft]);
à Lifting capacity table
