Rigging work
12.8 Rigging the auxiliary hoist
12 - 104 3 112 993 en Operating manual GMK 6400
12.07.2013
Releasing the
locking pin
• Open the safety valve; à p. 12 - 102.
• Press the button (1). The lamp lights up.
• Press the key combination (2), until the lamps (3) are lit.
If a locking pin has not yet reached the
Unlocked end position, the corres-
ponding lamp will flash.
• Close the safety valve for the transport; à p. 12 - 102.
Releasing the
locking pin
