Rigging work
12.9 Rigging work on the main boom
Operating manual GMK 6400 3 112 993 en 12 - 133
12.07.2013
Switching the air traffic control light on and off:
Removing You must remove the rod with the anemometer/air traffic control light
before driving on the road;
à p. 12 - 132.
• Switch off the air traffic control light – press the switch (1) upwards and
inwards.
• Remove the plug and close the sockets (4)
and (5) with the protective caps.
• Wind the cables onto the holders (2).
• Take the rod (1) out of the holder (3).
• For transportation, fasten the retaining pins
to the rod (1).
• If necessary, store the rod in the storage
compartment (1).
Switching on: Press in switch (1) at the bottom
Switching off: Press in switch (1) at the top
