MG MG6 Series 2011 User Manual

HVACSystem
HVACStructure
A/CPipe-EvaporatortoCompressorB-
CompressortoConnection
Remove
1.Disconnectbatteryearthlead.
2.RecoverrefrigerantfromA/Csystem.
Refrigerant Refrigerant
Refrigerant
recovery recovery
recovery
3.Remove1boltofclipsecuringA/CpipesBtobody
andremoveclip.
4.ReleasenutsecuringpipeBtocompressorand
disconnectpipeBfromcompressor.
Caution:Alwaystplugstoopenconnectionstoprevent
contamination.
5.RemoveanddiscardO-ringsfromA/Cpipes.
6.RemoveboltssecuringA/Cpipestoevaporator
connectorandremovepipeBbetweenevaporatorand
compressor.
Caution:Alwaystplugstoopenconnectionstoprevent
contamination.
7.RemoveanddiscardO-ringsfromA/Cpipes.
Ret
1.LubricatenewO-ringsandthreadsofplugwithclean
refrigerantoil.
2.Removeplug.
3.FitO-ringonbothsideofevaporator/compressorpipe
B.
4.PositionA/CpipeBbetweenoncompressorside,t
boltandtightento19-25Nm.
5.ConnectpipeAandpipeBbetweencompressorand
evaporator,tightennutto8-10Nm.
6.FitclipsecuringA/Cpipetobody,tightenboltto7-10
Nm.
7.RechargeA/Csystem.
Refrigerant Refrigerant
Refrigerant
recharging. recharging.
recharging.
8.Connectbatteryearthlead
A/CPipe-CondensertoEvaporatorA-
CondensertoConnection
Remove
1.Disconnectbatteryearthlead.
2.RecoverrefrigerantfromA/Csystem.
Refrigerant Refrigerant
Refrigerant
recovery recovery
recovery
3.Remove1boltofclipsecuringA/CpipesAtobody
andremoveclip.
4.ReleasenutsecuringpipeAandpipeBbetween
condenserandevaporator.
Caution:Alwaystplugstoopenconnectionstoprevent
contamination.
5.RemoveanddiscardO-ringsfromA/Cpipes.
6.Remove1boltsecuringA/Cpipestoevaporator
connectorandremovepipeAbetweencondenserand
evaporator.
Caution:Alwaystplugstoopenconnectionstoprevent
contamination.
7.RemoveanddiscardO-ringsfromA/Cpipes.
Ret
1.LubricatenewO-ringsandthreadsofplugwithclean
refrigerantoil.
2.Removeplug
3.FitO-ringonbothsideofevaporator/condenserpipeA.
4.PositionA/CpipeAtocondenserside,tboltand
tightento7-10Nm.
5.ConnectpipeAandpipeBbetweencondenserand
evaporator,tightennutto8-10Nm.
6.FitclipsecuringA/Cpipetobody,tightenboltto7-10
Nm.
7.RechargeA/Csystem.
Refrigerant Refrigerant
Refrigerant
recharging. recharging.
recharging.
8.Connectbatteryearthlead.
Version2.0480
