SuspensionSystem
RearSuspension
ServiceProcedures
UpperArm-Rear
Remove
1.Raisethevehicleonalift.
2.Removeroadwheel.
3.Remove3clipssecuringharnesstoupperarm.
4.OnRHupperarm,supportfueltankandremoveRH
rearfueltankstrapboltandpositionstrapaside.
5.Removeboltsecuringupperarmtotrailingarm.
6.Markpositionofupperarmtosubframebolt,remove
boltandremoveupperarm.
Ret
1.Positionupperarmtosubframe,tbolt,aligntomarks
butdonottightenatthisstage.
2.Positionupperarmtotrailingarm,tboltbutdonot
tightenatthisstage.
3.OnRHupperarm,positionRHrearfueltankstrap,
tightenboltto21–25Nmandremovesupport.
4.Fitclipssecuringharnesstoupperarm.
5.Retroadwheelandtightenboltsto115–130Nm.
6.Lowerthevehicle.
7.Tightenboltsecuringupperarmtosubframeto
90–110Nm.
8.Tightenboltsecuringupperarmtotrailingarmto
90–110Nm.
Caution:Nutsandboltsmustbetightenedwithweightof
vehicleonsuspension.
9.Checkrearwheelalignment.
Wheel Wheel
Wheel
Alignment Alignment
Alignment
Version2.0578
