Safety precautions
ii
Waring
To minimize the risk of unforeseen accidents, avoid installing CSD-912B in the
following locations.
- Hot locations or locations exposed to direct sunlight.
- Damp locations.
- Locations subject to vibration or impact.
- Dusty locations.
- Environments containing corrosive gases or salt, etc.
/RFDWLRQVVXEMHFWWRVXGGHQWHPSHUDWXUHRUKXPLGLW\ÀXFWXDWLRQV
- Close to equipment that generates magnetic or electromagnetic radiation.
- Locations subject to radioactivity and radiations.
- Locations such as laboratories where chemical changes may occur.
Caution
Install CSD-912B based on the following dimensions. Be sure to secure enough
space surrounding the instrument.
The following is the dimensions of CSD-912B and surrounding spaces required.
Rear
Front Side
192 131.5 (18.2)
Unit: mm
187
92
96
185
91
Panel cut size
20
+1
0
+1
0
