22
Getting Started
RS-422 Connection Diagram
Kaleido-X (7RU)
Kaleido-X (14RU)
Refer to the “Kaleido-X (7RU) Expansion” chapter in the Kaleido-X (7RU) Hardware
Description & Installation Manual.
RS-422 Connection Diagram
In the case of a Kaleido-X multiviewer, each output card supports one RS-422 port over an
RJ-45 connector. The Kaleido-X16 supports two RS-422 serial inputs over RJ-45 connectors.
Note: For information on the KMV-3911 multiviewer’s RS-422 interface,
refer to the KMV-3911 Guide to Installation and Operation, available on the
DVD that shipped with your system, and from Miranda’s support portal.
