USE MANUAL
MINISENTRY-2
92 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S, BP249, ZI de Vauzelles, 3760
2
Loches Cedex
4. Click on theStart” button. The high voltage plateau appears on the plot area.
5. You may program one of the values represented on the graph curve into the connected device.
Proceed as follows:
Put the mouse cursor onto one of the points of the curve;
Click on the curve point with the left button of the mouse. The context menu shown
on the following screenshot appears.
Click on the command “Set up this value”. The dialog box shown on the following
screenshot appears.
When prompted, click on the “Yes” button. After the write process, a new
confirmation box appears, as shown on the following screenshot.
Click on theOK” to close the confirmation box.
6. Close the “High Voltage plateau” window, as shown on the following screenshot.
