Installation
114
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
In a direct connection the RJ45 connector is connected directly to the trunk cable using
a crimp clip.
With an indirection connection you need to observe the cable requirements.
Note
Circuit type as per EN/IEC 60950: TNV-3
Connection
Assignment of the RJ45 sockets on the front panel:
Tab. 48 Connection FXO network interface
Cable Requirements
Tab. 49 Cable requirements for FXO network interface
4. 7. 3 Terminal interfaces
The number of available terminal interfaces on the mainboard can be increased by fit-
ting interface cards.
The RJ45 connector assignment is the same for interfaces of the mainboard and termi-
nal cards.
Public analogue network
Communication server
FXO signal Pin Socket
–1
–2
–3
a4
b5
–6
–7
–8
Core pairs
×
cores 1
×
2
Stranded not required
Wire diameter, core 0.4 … 0.8 mm
Screening not required
Resistance max. 2
×
250
Ω
