3 Expansion Stages and System Capacity
The basic systems can be expanded using interface cards, system modules and li-
cences. The expansion possibilities available and the maximum system capacities
need to be known so the communications system can be ideally adapted to cus-
tomer requirements. With the project data the optimum hardware configuration is
easily determined using the project planning application Mitel CPQ.
3. 1 Summary
The expansion possibilities of the basic systems Mitel 415 and Mitel 430 at a glance.
The equipment is powered by an external power supply. The same power supply unit is
used for Mitel 415 and Mitel 430.
The mounting options are described in the Chapter "
Fitting the communication server",
page 82.
Fig. 6 Overview of the expansion possibilities
2 x BRI-T/S
TIC-2TS
3 x BRI-T/S, 1 x BRI-T
TIC-4TS
2 x FXO
TIC-2AB
4 x FXO
TIC-4AB
1 x PRI
TIC-1PRI
4 x DSI
EADP4
4 x FXS
ETAB4
1 x DSP
SM-DSPX1
2 x DSP
SM-DSPX2
T/S Typ0
WA-TS0
T/S Typ1
WA-TS1
2 Draht
WA-2W
PRI
WA-1PRI
Door/Outputs/Inputs
ODAB
Mitel 430
basic system
Mitel 415
basic system
Rack-mounting set
Mitel 430
Rack-mounting set
Mitel 415
Cable cover se t
Mounting
options
Wiring adapter
System
module
Interface cards
Communica-
tion server
FXS: Foreign Exchange Station
FXO: Foreign Exchange Oce
DSI: Digital Station Interface
