Please note:
• The arrows on the wiring adapters specify the plug-in orientation of the required port
assignment.
• On the ESST terminal card the jumper must always be fitted in position T (see figure
below). The port assignment is specified by the wiring adapter alone.
WA-TS1 TIC-4TS
1)
SSTT S S T T
TIC-4TS
1)
SSST S S S T
TIC-2TS
1)
SSTT S S – –
TIC-2TS
1)
SSST S S – –
ESST
1)2)
SSTT S S – –
ESST
1)2)
SSST S S – –
ODAB SSTT I/O 1,2 I/O 3,4 ab/Door
Intercom
–
WA-2W ETAB4
3)
– FXS FXS FXS FXS
EADP4
3)
– DSI DSI DSI DSI
EAD4C
1)
– DSI DSI DSI DSI
EAD4V
1)
– DSI DSI DSI DSI
EAAB2
1)
–––FXOFXO
TIC-4AB – FXO FXO FXO FXO
TIC-2AB – FXO FXO – –
WA-1PRI TIC-1PRI – PRI Test
4)
––
1) The wiring adapter is not part of the equipment supplied with this interface card and must be ordered sepa-
rately.
2) On the ESST terminal card the jumper must always be fitted in position T (see Fig. 24
).
3) The wiring adapter is only part of the equipment supplied with order variant Mitel 415/430.
4) For test purposes the PRI interface is also routed in parallel to port X.2.
Wiring Adapter Interface card
Plug-in ori-
entation
Port number
X.1 X.2 X.3 X.4
