Different actions are carried out depending on how long the key is pressed and the
system’s current operating state. The duration of the keypress is divided into three time
intervals:
Tab. 90 Keypress duration, pilot key
6. 4. 3 Operating modes and display priorities
The system software of the Mitel 415/430 recognizes various operating modes, which
are displayed with the LEDs F0, F1, F2, F3, F4 and SYS. In the following these dis-
plays are referred to as combination patterns or patterns and are numbered for easy
reference.
The various operating modes have different display priorities, i.e.a mode with a higher
display priority will cover up the combination pattern of a mode with a lower display pri-
ority. The combination patterns covered up are stored and continually updated in the
background, which means that no patterns are lost.
The table below lists all the operating modes and their display priorities. The highest
display priority is 1; the lowest, 7.
Tab. 91 Operating modes and display priorities
Designation ID Keypress duration
Short keypress (Shortclick) SC 0...2 seconds
Long keypress (Long Click) LC 2...10 seconds
Very long keypress (Very Long Click) VLC More than 10 seconds
Operating mode
Display pri-
ority
Remarks
Shutdown Mode 1 • After the system is shut down
• Shutdown mode lasts for 3 minutes. Thereafter the system
automatically changes to Startup Mode
.
Error Mode
1 • System is no longer able to run
Startup Mode
2 • When power is supplied
• After a restart/first start
• Used as a progress indicator during startup
Application Command Mode
Boot Command Mode
3 • Used for carrying out certain functions
• This mode is exited automatically if no input is made within 20
seconds.
Warning Mode
4 • System is still capable of running but the system function may
be impaired.
• Problem needs to be remedied as soon as possible.
Wiring Adapter Malfunction Mode
5 • System is running but a problem has been detected on one or
more wiring adapter slots.
Feature Mode
6 • System is running normally but one function is active.
Normal Mode
7 • System is running normally.
