Expansion Stages and System Capacity
54
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
3. 3. 2. 3 Options card
The ODAB options card contains control outputs, control inputs and an analogue termi-
nal circuit for connecting a door intercom (TFE). The I/Os of the options card are partly
configurable and can be used for the following purposes:
• The control outputs are used to switch any external devices or equipment. Any au-
thorized user can operate the control ouputs.
• Floating contacts are connected to the control inputs. This means that the con-
nected control inputs can control switch group positions.
• Connection of a door intercom (TFE):
– Bell input, which can be configured to any internal destination depending on the
position of a switch group.
– Door intercom system, which can be dialled using a separate number and oper-
ated via a phone by any authorized user.
– Door opener, which can be activated via a phone by any authorized user.
– Input for feeding the voice path (switching the door intercom on/off).
Tab. 26 Options card
Note
If the options card is used to connect a door intercom, it must be fitted to slot IC2 (Mitel 415) or
slot IC4 (Mitel 430). This means that only one options card can be used for this purpose on
each communication server. If using control outputs and control inputs only, use the slots IC1
slots (Mitel 415) or IC1, 2 and 3 (Mitel 430).
Mitel Advanced Intelligent Network:
A total of 22 ODAB options cards can be used in an AIN with Mitel 430 as Master. However the
maximum number of cards per communication server has to be taken into account. An author-
ized user has the possibility of operating all the door openers, door intercom system and control
outputs in an AIN. One of the switch groups can be switched over using the switch group inter-
face on the options cards.
Type
Control outputs
or control inputs
Analogue terminal circuit for
connecting a door intercom
Max. number of
Mitel 415 cards
Max. number of
Mitel 430 cards
ODAB 4
1)
1) 1 control output or 1 control input is available in the configuration as a door intercom. If the option card is
used for other purposes, 2 control outputs and 2 control inputs can be used.
112
