7. 2 Rating Plate and Designation Stickers
Fig. 86 Rating plate (example Mitel 430 communication server)
Fig. 87 Designation stickers (example interface card)
7. 3 Equipment Overview
Tab. 115 Equipment Overview
ID ETAB4 = analogue terminal card with 4 FXS interfaces
Colour code on terminals Colour designation in accordance with EU directive
Generation and version Example: –3C = 3. Generation, Version C
(Generation new modules: -1)
Notes:
• A generational change is effected following substantial changes
to the functionality of a PCB.
• A change of version is effected following small changes to func-
tions or once faults have been remedied. Backward compatibility
is guaranteed.
Designation Description
PBX957.EXP.A415-2 Mitel 415 basic system with power supply unit and power cable
PBX957.EXP.A430-2 Mitel 430 basic system with power supply unit and power cable
MOV957.EXP.SM-DSPX1-1 DSP module SM-DSPX1
MOV957.EXP.SM-DSPX2-1 DSP module SM-DSPX2
Part of the PCB designation Remarks and examples
Production date
Material no.
PCB designation
System
Type
approval
Power
specication
Serial number
MOV957. EXP.TIC-2TS-1
P . . . . - 20 . . . . . .
Mat. No. PCB Designation
No.
