Operation and Maintenance
236
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
The system status of the communication server in the SRM agent remains on
Critical, and the destinations on red, because there is still an event message with
this severity.
4. The event message Fan failure reaches the SRM server.
The communication server's system status in the SRM agent changes to Normal,
and the destinations turn red.
After a first-start of the communication server, the SRM destination is automatically al-
located event table 7. The notification service to the SRM destination can be switched
on or off.
On the SRM server the status modification per communication server must be allowed
and configurations are also required in WebAdmin. You can find a configuration guide
in WebAdmin help under the Message destinations =h1 view.
Testing the signal destination configuration
To test the configuration, a test event message can be separately initiated for each
destination in the WebAdmin configuration (Message destinations =h1 view). The
event message is signalled without any delay, directly at the selected signal destina-
tion.
If the communication server is connected via a modem or terminal adapter, the test
event messages will be signalled only once the connection is cleared down.
6. 5. 2 Operating state and error displays
6. 5. 2. 1 System operating state
During the start-up phase, various self-tests are performed and the individual phases
are shown in the LED display on the front panel (see "
Startup Mode", page 203).
When operation is OK, the SYS LED flashes green, regularly, and once per second in
the display on the front panel. The system is in normal mode. The assignment of inter-
nal or external ports, password-free access as well as remote access via an external
dial-up connection to AIN are shown as status in the LED display (see "
Normal Mode",
page 203 and "Feature Mode", page 204).
6. 5. 2. 2 System error displays
Whenever the system detects an error, it displays the corresponding error code in the
LED on the front panel (providing the communication server is still powered and the
display is working).
