Mitel 430 - Audio Interface

Installation
143
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Switch group interface
The routing elements of switch groups are controlled via control inputs I3 and I4. Con-
trol is effected using external switches (door contacts, time switches, etc.). The signal
no-load voltage is approx. 40 VDC, the short-circuit current approx. 4 mA.
The permissible switch and loop resistances are as follows:
• Active state (On): < 4.5 kΩ
• Passive state (Off): > 11 kΩ
Warning
The control inputs do not require an external power supply but they must have a floating con-
nection.
There are no special requirements for the cables.
Tab. 71 Switch group control via the control inputs
Other conditions:
• The switch group configuration determines which of the switch groups are switched.
• An options card’s control inputs can control one or more switch groups.
• The same switch group can only be switched by the control inputs of one options
card.
• Control of the switch groups using the control inputs takes priority over control using
function codes.
4. 7. 6 Audio interface
The audio interface can be used for the following purposes:
• to play music or an announcement to connections with callers on hold ("Music on
hold" function).
• to play music or an announcement for the announcement service (announcement
prior to answering), voice mail greetings or for "Music on hold" and then to store it as
a wave file.
Any playback equipment (tape recorder, CD player, etc.) with a line output can be used
as the audio source.
The customer is responsible for all copyright matters relating to any music playback.
Control input I3 Control input I4 Switch positions of the switch groups
Off Off Position 1
On Off Position 2
any On Position 3
