Mitel 430 - Rack-Mounting Procedure

Installation
90
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
4. 2. 7. 1 Rack-mounting procedure
Materials required:
• Mitel 415 and Mitel 430 rack-mounting kit
• Screw set for wall/desktop installation
• Screwdriver
To rack-mount an Mitel 415/430 proceed as follows:
1. Pull off the screw covers on the left and right of the front panel.
2. Secure the mounting plates to the communication server using the M4 screws.
Make sure the front panel and the mounting plate are aligned.
3. Shut down the communication server (see "
Shutdown Mode", page 206) and dis-
connect it from the power supply.
Warning
Be sure to observe the "Safety regulations", page 84.
4. Remove the housing cover.
5. Mitel 430 only:
Install the fan (see "
Installing the fan", page 91).
6. Connect the earthing (see "
Connecting the earthing wire", page 93).
7. Fit the housing cover.
8. Secure the cage nuts in the appropriate positions in the rack’s fastening rails (see
Fig. 16).
9. Secure the communication server to the rack’s fastening rails using the M6 screws,
the plastic washers and the cage nuts.
10.Fasten the snap-on tag to the front panel.
11.Reconnect the communication server to the power supply.
