Annex
248
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
– Voice path with A/D and D/A conversion (standard PCM, A-law)
– Transmission as per ES 201 168 (level country-specific)
– Constant-current loop supply approx. 25 mA (with loop resistance ≤ 1000 Ω)
– Receive pulse or DTMF dialling
– CLIP display on all analogue terminal interfaces (Mitel 415/430 only on 2 ana-
logue terminals simultaneously).
– Ringing supply 40…43 V 50 Hz at load 4kΩ; no DC voltage overlay (country-spe-
cific versions also with 25 Hz)
– No control key detection
– No charge signalling pulses
• For more technical details and cable requirements see "
Multifunctional FXS inter-
faces", page 127.
7. 4. 3 Communication server
Tab. 117 Dimensions and weights
Tab. 118 Electrical isolation of interfaces
Tab. 119 Ambient conditions
Mitel 415/430 for wall
mounting
Mitel 415/430 in rack
mounting
Height 65 mm 65 mm
Width 360 mm 483 mm
Depth 294mm 294mm
Weight (excl. mains cord, interfaces cards, modules and
packaging)
2.4 kg 2.5 kg
Interface Mitel 415/430
Analogue network interfaces 0.2 kV Operating isolation
Digital network interfaces BRI Operating isolation
Control input on ODAB no isolation, but input impedance > 8 k
Ω
Freely connectable relay contacts on ODAB 0.2 kV
Door intercom interface on ODAB 0.2 kV
Control input on FXS interface no isolation
Control output on FXS interface no isolation
Audio input no isolation
Condition Mitel 415/430
Ambient temperature 5 °C to 45 °C
Relative air humidity 30 % to 80 %, non-condensating
