Operation and Maintenance
212
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
6. 4. 4. 7 Resetting the IP address
The IP address data is stored on the EIM card and is retained even after a first start.
The following sequence only resets the IP address data of the communication server to
the default values. All the other data is retained.
Requirement:
The system is in "
Boot Command Mode", page 205.
1. Press the pilot key several times with a short keypress (SC) until "F2" lights up red.
2. Press the pilot key with a long keypress (LC)
→ After 2 second keypress "F2" lights up green by way of confirmation.
→ The IP address data is reset to the default values once the key is released. The
startup then continues normally.
Default values of the IP address data:
• IP address: 192.168.104.13
• Subnet mask: 255.255.255.0
• Gateway: 0.0.0.0
6. 4. 4. 8 Thorough RAM test
To carry out a thorough RAM test during startup, press the pilot key briefly (SC) during
the orange LED test (pattern[2]). The thorough RAM test lasts for approx. 2 minutes
and is displayed with Pattern [4]
. The startup then continues normally.
6. 4. 4. 9 Emergency Upload via LAN
An Emergency Upload is required whenever there is no longer any executable system
software stored on the communication server for whatever reason or if a downgrade to
an older software version is to be carried out.
For this, proceed as described in "
Loading new or older system software with System
Search", page 186.
