Expansion Stages and System Capacity
80
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Tip
With the planning application Mitel CPQ the power supply available for terminals is checked
automatically.
Overload shutdown
If the rated power is exceeded the power supply is disconnected. It is restored after ap-
prox. 20 s.
If an overload occurs, reduce the required supply power (e.g. by powering DECT radio
units and/or system phones locally).
3. 4. 10. 2 Power supply per terminal interface
The power supply per terminal interface is determined by the interface type. The inter-
face load depends on the following variables:
• Terminals used incl. auxiliary devices
• Bus configuration
• Line length and conductor cross-section
For information on the calculations refer to "
Terminal interfaces", page 114.
Office 25
1)
DSI-AD2 interface 380
Office 35
1)
DSI-AD2 interface 280
5)
Office 45/45pro
1)
DSI-AD2 interface 660
5)
Office 45pro power supply unit
1)
DSI-AD2 interface < 10
Expansion key module (EKP)
1)
Office 35, Office 45 80
Alphanumerical keyboard (AKB)
1)
Office 35, Office 45 20
ISDN terminal BRI-S interface approx. 500
6)
Analogue terminals FXS interface approx. 500
1) Although no longer available, the phone is still supported.
2) An MiVoice M535 always requires a power supply unit
3) The value applies to radio units with hardware version "-2". The value for hardware version "-1" is 300 mW
lower.
4) The value applies to each interface and to radio units with hardware version "-2". The value per interface for
radio units with hardware version "-1" is 150 mW lower.
5) The value applies to phones with hardware version "-2". The value for phones with hardware version "-1" is
60 mW lower.
6) The value depends greatly on the terminal type.
Terminals Socket Output P [mW]
