Installation
83
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
4. 2. 2. 3 Mitel 430 rack-mounting set
Equipment supplied:
• 2 mounting plates for rack installation
• Screw set
•Fan
4. 2. 3 Location requirements
The following location requirements must be observed when positioning the communi-
cation server.
Hazard
Failure to observe the location requirements can cause the communication server to overheat,
damaging electrical components and/or the surrounding area.
An event message is generated if the heat dissipation is insufficient. Appropriate measures
must be taken immediately to improve the heat dissipation, e.g. by providing the required clear-
ances, lowering the ambient temperature or installing the fan from the rack-mounting set
(Mitel 430 only).
Tab. 34 Mitel 415/430 Location requirements
Heat radiation • Do not position in direct sunlight, near radiators or near other heating sources
EMC • Do not position in strong electromagnetic fields of radiation
(e.g.near x-ray equipment, welding equipment or similar).
Heat dissipation • Do not place any objects on top of the communication server.
• Observe the clearance requirements for wall mounting and desktop installation (see Fig. 12
and Fig. 13
).
• In a rack-mounted installation the space to the left and right between the communication server
and the wall of the 19” rack must remain empty. The installation of a fan is also mandatory for
the Mitel 430.
Environment • Ambient temperature 5 °C...45 °C
• Relative humidity 30…80%, non-condensing
