Mitel 430 - Design of Interface Cards, Modules and Wiring Adapters

Annex
249
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Tab. 120 Electrical data
Tab. 121 Heat dissipation
7. 4. 4 Design of interface cards, modules and wiring adapt-
ers
Tab. 122 Design
Mitel 415 Mitel 430
Class of protection 1
Input voltage 95 V…253 V, 48…62 Hz
Input current approx. 0.11 A...0.7 A approx. 0.11 A...1.0 A
Resistant to voltage breaks < 6ms
Power input with min. configuration approx. 15 W approx. 15 W
Power input with max. configuration approx. 50 W approx. 75 W
Undervoltage limit
(system reset, data backup)
< 90 V
Mitel 415 Mitel 430
Maximally configured system approx. 37 W = 135 kJ/h approx. 50 W = 180 kJ/h
Card/module Design
TIC-4TS B
TIC-2TS B
ESST C
TIC-4AB B
TIC-2AB B
TIC-1PRI C
EAAB2 B
EADP4 C
EAD4V A
EAD4C A
ETAB4 B
ODAB C
SM-DSP1 D
SM-DSP2 D
SM-DSPX1 D
SM-DSPX2 D
WA-TS0 F2
WA-TS1 F2
WA-2W F1
WA-1PRI F1
