Installation
81
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
4 Installation
This Chapter tells you how Mitel 415/430 can be installed and the conditions to be
observed. It also includes the mounting into a 19” rack, the correct way to connect
the earthing, and the power supply. Other topics described in this Chapter comprise
fitting with system modules, interface cards and the relevant Wiring Adapters. Finally
the Chapter also describes the network- and terminal-side connection of the inter-
faces and the installation, powering and connection of system terminals.
4. 1 System components
The figure below shows the components of the Mitel 415/430 communication server
complete with mounting options.
Fig. 11 System components with mounting options
Left-hand bracket
for cable cover
Right-hand bracket
for cable cover
Power cord
Fan
Power supply
Cable cover
Snap-on tag
Front panel
Screw covers
Mounting plate
for rack
installation
Left-hand bracket
for cable cover
Plastic cover with
Screening
Mainboard
Fan-out-panel
EFOP
