Expansion Stages and System Capacity
58
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Backup communication servers for Dual Homing 50 50 50
Primary communication servers for Dual Homing 50 50 50
Blacklist 1 1 1
Call number entries in the blacklist 1000 1000 1000
Number of CLIP based routing tables 10 10 10
Total call number entries in call distribution tables 250 250 250
Call data memory internal (number of records)
14)
300 300 300
Private contacts 8000 8000 8000
Call list entries for each of the 3 call lists per phone 30 30 30
Total call list entries 15000 15000 15000
Configured keys 4000 4000 4000
Busy lamp field keys on Mitel SIP phones in total 200 200 200
Busy lamp field keys per Mitel SIP phone 50 50 50
Same users on busy lamp field keys on Mitel SIP phones 10 10 10
Expansion key modules on DSI terminals 30
4)
60 100
Expansion key modules on IP system phones 30
4)
60 100
Expansion key modules Mitel M670, Mitel M675, Mitel M680,
Mitel M685
30
4)
60 100
Alpha keyboardMitel K680 10 50 50
Alpha keyboard (AKB) 10 40 50
1) Up to 20 users are possible with virtual terminals and integrated mobile/external phones.
2) Up to 100 users are possible with virtual terminals and integrated mobile/external phones.
3) Only 1 operator console, 1 MiVoice 2380 IP, 1 BluStar 8000i , 1 Mitel BluStar for PC, 1 Mitel SIP-DECT and
2 DECT- cordless phones are possible for each user.
4) Limited by the maximum number of terminals
5) In the Secure VoIP modes the maximum values cannot be achieved with the selection i the DSP settings:
Mitel 415: Secure G.711 VoIP mode: 1 7 = 7 channels, VoIP mode Secure G.711/G.729: 1 × 5 = 5 channels.
Mitel 430: Secure G.711 VoIP mode: 2 7 = 14 channels, VoIP mode Secure G.711/G.729: 3 × 5 = 15 chan-
nels.
6) For IP-IP connections maximum 8
7) Audio channels can be used for voice mail, auto attendant, queue with announcement, call recording, an-
nouncement with audio file, or conference bridge. Announcement service and music on hold use their own
resources.
8) Of relevance only to certain countries such as Brazil
9) 12 of them are masked (not configurable)
10)With global call distribution
11)Depending on the phone type
12)The value applies to CDE with destination KT line. With MiVoice Office 400 multiple destinations (User + KT
or KT + UG) the value is reduced to 4.
13)Depending on the highest number of line keys, configured for the same line. The following pairs apply (line
keys per line / total line keys): (8/24), (7/28), (6/36), (5/50), (4/60), (3/60), (2/60), (1/60).
14)The call data memory is only used if the output destination is blocked (e.g. printer jam).
Max. number... Mitel 415 Mitel 430
AIN with
Mitel 430 as
Master
