PROTOCOL-SPECIFIC INFORMATION
259
9
Register
The inverter register (in section 4) associated with this object. For the Generic Status object, enter a
“status” register to be monitored. For the Generic Control object, enter a “command” register that can be
written.
Data Type
Each data word is fixed to 16-Bit Unsigned. This is equivalent to two bytes.
Include in DataSet
Include or exclude this object from the fixed dataset.
The default configuration is described in Table 58. Always use the studio to confirm the configuration
before commissioning the device.
Table 58: IEC 61850 Server User-Configurable I/O
Type
Name
Instance
Register
Generic Status
Status0
0
100
Generic Status
Status1
1
201
Generic Control
Control0
0
1
Generic Control
Control1
1
2

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
