FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
100
6 Examination of System Configuration
6.5 Expansion of Main Unit (Calculation of Current Consumption)
6.5.2 When special extension devices are also added [calculation of current
consumption] (AC Power Supply/DC Input Type)
1 Select a main unit.
Select a main unit.
Select one main unit appropriate to the required number of input/output points from the following table.
When the number of input/output points is insufficient, add input/output extension blocks.
2 Enter the specifications for the selected main unit.
Enter the number of input/output points and power supply type of the main unit according to the
above table.
Classification Type
Input
specifi-
cations
Output
specifications
Number of
input/
output
points
[points]
Capacity of built-in power supply
5V DC power
supply [mA]
24V DC service
power supply
[mA]
main unit
FX3U-16MR/ES
24V DC
Relay 16
500
400
FX3U-16MT/ES Transistor (sink) 16
FX
3U-16MT/ESS Transistor (source) 16
FX3U-32MR/ES Relay 32
FX3U-32MT/ES Transistor (sink) 32
FX3U-32MT/ESS Transistor (source) 32
FX3U-32MS/ES Triac 32
FX3U-48MR/ES Relay 48
600
FX3U-48MT/ES Transistor (sink) 48
FX3U-48MT/ESS Transistor (source) 48
FX3U-64MR/ES Relay 64
FX3U-64MT/ES Transistor (sink) 64
FX3U-64MT/ESS Transistor (source) 64
FX3U-64MS/ES Triac 64
FX3U-80MR/ES Relay 80
FX3U-80MT/ES Transistor (sink) 80
FX3U-80MT/ESS Transistor (source) 80
FX3U-128MR/ES Relay 128
FX3U-128MT/ES Transistor (sink) 128
FX3U-128MT/ESS Transistor (source) 128
Classification
Number of
connected
units
Type
Number of
input/output
points [points]
Capacity of built-in power supply
5V DC power
supply [mA]
24V DC service
power supply
[mA]
With built-in
power
supply
main unit
1FX3U-
Example of entry→ FX3U-32MR/ES 32 500 400
A
1 -1
1 -2 1 -3
A
1
1 -1
1 -2 1 -3
A
