FX3U Series Programmable Controllers
User's Manual - Hardware Edition
77
5 Version Information and Peripheral Equipment Connectability
5.2 Programming Tool Applicability
1
Introduction
2
Features and
Part Names
3
Product
Introduction
4
Specifications
5
Version and
Peripheral
Devices
6
System
Configuration
7
Input/Output
Nos., Unit Nos.
8
Installation
9
Preparation and
Power Supply
Wiring
10
Input Wiring
5.2 Programming Tool Applicability
5.2.1 Applicable versions of programming tool
1. GX Works2
• GX Works2 Japanese version (SWDNC-GXW2-J) is applicable to FX3U PLCs from the following
versions.
• GX Works2 English version (SWDNC-GXW2-E) is applicable to FX3U PLCs from the following versions.
2. GX Developer
• GX Developer Japanese version (SWD5C-GPPW-J) is applicable to FX3U PLCs from the following
versions.
*1. For Ver. 8.23Z or 8.24A of GX Developer, the PLC type is FX3UC.
*2. Ver. 8.88S and later versions support the baud rate "38400 bps" in the communication setting for RS
and RS2 instructions, inverter communication and computer link.
• GX Developer English version (SWD5C-GPPW-E) is applicable to FX
3U PLCs from the following
versions.
*3. For Ver. 8.24A of GX Developer, the PLC type is FX3UC.
*4. Ver. 8.89T and later versions support the baud rate "38400 bps" in the communication setting for RS
and RS2 instructions, inverter communication and computer link.
FX3U PLC version
Model name
(Media model name
is shown below.)
Applicable
GX Works2 version
Remarks
Before Ver. 2.70
GX Works2
SWDNC-GXW2-J
Ver. 1.07H or later
• Model selection: FX3U/FX3UC
Before Ver. 3.00 Ver. 1.45X or later
Before Ver. 3.10 Ver. 1.56J or later
Ver. 3.10 Ver. 1.73B or later
FX3U PLC version
Model name
(Media model name
is shown below.)
Applicable
GX Works2 version
Remarks
Before Ver. 2.70
GX Works2
SWDNC-GXW2-E
Ver. 1.08J or later
• Model selection: FX3U/FX3UC
Before Ver. 3.00 Ver. 1.48A or later
Before Ver. 3.10 Ver. 1.62Q or later
Ver. 3.10 Ver. 1.73B or later
FX3U PLC version
Model name
(Media model name
is shown below.)
Applicable
GX Developer version
Remarks
Before Ver. 2.30
GX Developer
SWD5C-GPPW-J
Ver. 8.23Z or later
• Model selection: FX3U(C)
*1
Before Ver. 2.41 Ver. 8.29F or later
• Model selection: FX3U(C)
Before Ver. 2.61
Ver. 8.29F or later
*2
Ver. 2.61
Ver. 8.82L or later
*2
FX3U PLC version
Model name
(Media model name
is shown below.)
Applicable
GX Developer version
Remarks
Before Ver. 2.30
GX Developer
SWD5C-GPPW-E
Ver. 8.24A or later
• Model selection: FX3U(C)
*3
Before Ver. 2.41 Ver. 8.29F or later
• Model selection: FX3U(C)
Before Ver. 2.61
Ver. 8.29F or later
*4
Ver. 2.61
Ver. 8.82L or later
*4
