FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
362
18 Other Extension Devices and Optional Units (External Dimensions and Terminal Arrangement)
18.1 Special Function Units/Blocks
18.1.13 FX2N-8AD
External Dimensions
•MASS(Weight): 0.4kg (0.88lbs)
•Installation: 35mm (1.38") wide DIN rail
or screws
•Accessories: Label for indication of special
unit/block number,
Manual supplied with product
•Terminal block: M3.5 screws
•The extension cable is already connected to
the extension block
Terminal Layout
18.1.14 FX3U-2HC
External Dimensions
•MASS(Weight): 0.2kg (0.44lbs)
•Installation: 35mm (1.38") wide DIN rail
or screws
•Accessories: Label for indication of special
unit/block number,
Dust proof sheet,
Manual supplied with product
•Connector: 40-Pin
•The extension cable is already connected to
the extension block
Terminal Layout
75(2.96")
8(0.32")
98(3.86")
(mounting hole pitch)
105(4.14")
90(3.55")
Unit:mm (inches)
75(2.96")
67(2.64")
(mounting hole pitch)
2-φ4.5 mounting holes
24+ 24-
V1+ I1+
V2+ I2+
COM1
COM2
V3+
V4+
I3+
I4+
COM3
COM4
V5+ I5+
I6+
COM6
COM5
V7+
V8+
I7+
I8+
COM7
COM8
V6+
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
Unit:mm (inches)
4(0.16")
55(2.17")
2-φ4.5 mounting holes
9(0.36")
A
24+
CH1
A5+
B24+
B5+
P24+
P5+
XD24
YH1+
YH2+
A12+
A-
B12+
B-
P12+
P-
XD5
COMD
YH1-
YH2-
A24+
CH2
A5+
B24+
B5+
P24+
P5+
XD24
YH1+
YH2+
A12+
A-
B12+
B-
P12+
P-
XD5
COMD
YH1-
YH2-
Notch Notch
