A Operation of Special Devices (M8000 -, D8000 -)
A-3 Analog special adapters [M8260 to M8299 and D8260 to D8299]
21
Memory Cassette
22
Battery
A
Special Devices (M8000-,D8000-)
B
Instruction List
C
Character-code
D
Discontinued models
E
Precautions for battery transportation
F
Handling of batteries in EU member states
Appendix A-3-2 Special data registers (D8260 to D8299)
Number
Operation and function
FX3U-4AD-ADP FX3U-4DA-ADP
FX3U-3A-ADP
Applicable version
From first version From first version Ver. 2.61 or later
1st analog special adapter
D 8260 Input data Ch1 Output data Ch1 Input data Ch1
D 8261
Input data Ch2 Output data Ch2 Input data Ch2
D 8262
Input data Ch3 Output data Ch3 Output data
D 8263
Input data Ch4 Output data Ch4 Not used
D 8264
Number of averaging times for Ch1
(1 to 4095)
Not used
Number of averaging times for Ch1
(1 to 4095)
D 8265
Number of averaging times for Ch2
(1 to 4095)
Not used
Number of averaging times for Ch2
(1 to 4095)
D 8266
Number of averaging times for Ch3
(1 to 4095)
Not used Not used
D 8267
Number of averaging times for Ch4 (1
to 4095)
Not used Not used
D 8268 Error status Error status Error status
D 8269
Model code: K1 Model code: K2 Model code: K50
2nd analog special adapter
D 8270 Input data Ch1 Output data Ch1 Input data Ch1
D 8271
Input data Ch2 Output data Ch2 Input data Ch2
D 8272
Input data Ch3 Output data Ch3 Output data
D 8273
Input data Ch4 Output data Ch4 Not used
D 8274
Number of averaging times for Ch1
(1 to 4095)
Not used
Number of averaging times for Ch1
(1 to 4095)
D 8275
Number of averaging times for Ch2
(1 to 4095)
Not used
Number of averaging times for Ch2
(1 to 4095)
D 8276
Number of averaging times for Ch3
(1 to 4095)
Not used Not used
D 8277
Number of averaging times for Ch4
(1 to 4095)
Not used Not used
D 8278 Error status Error status Error status
D 8279
Model code: K1 Model code: K2 Model code: K50
3rd analog special adapter
D 8280 Input data Ch1 Output data Ch1 Input data Ch1
D 8281
Input data Ch2 Output data Ch2 Input data Ch2
D 8282
Input data Ch3 Output data Ch3 Output data
D 8283
Input data Ch4 Output data Ch4 Not used
D 8284
Number of averaging times for Ch1
(1 to 4095)
Not used
Number of averaging times for Ch1
(1 to 4095)
D 8285
Number of averaging times for Ch2
(1 to 4095)
Not used
Number of averaging times for Ch2
(1 to 4095)
D 8286
Number of averaging times for Ch3
(1 to 4095)
Not used Not used
D 8287
Number of averaging times for Ch4
(1 to 4095)
Not used Not used
D 8288 Error status Error status Error status
D 8289
Model code: K1 Model code: K2 Model code: K50
4th analog special adapter
D 8290
Input data Ch1 Output data Ch1 Input data Ch1
D 8291
Input data Ch2 Output data Ch2 Input data Ch2
D 8292
Input data Ch3 Output data Ch3 Output data
D 8293
Input data Ch4 Output data Ch4 Not used
D 8294
Number of averaging times for Ch1
(1 to 4095)
Not used
Number of averaging times for Ch1
(1 to 4095)
D 8295
Number of averaging times for Ch2
(1 to 4095)
Not used
Number of averaging times for Ch2
(1 to 4095)
D 8296
Number of averaging times for Ch3
(1 to 4095)
Not used Not used
D 8297
Number of averaging times for Ch4
(1 to 4095)
Not used Not used
D 8298 Error status Error status Error status
D 8299
Model code: K1 Model code: K2 Model code: K50
