FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
A Operation of Special Devices (M8000 -, D8000 -)
A-3 Analog special adapters [M8260 to M8299 and D8260 to D8299]
Number
Operation and function
FX3U-4AD-PT(W)-ADP FX3U-4AD-TC-ADP FX3U-4AD-PNK-ADP
Applicable version
From first version From first version From first version
1st analog special adapter
M 8260 Temperature unit selection Temperature unit selection Temperature unit selection
M 8261
Not used Type-K/-J switching Input sensor selection
M 8262
Not used Not used Not used
M 8263
Not used Not used Not used
M 8264
Not used Not used Not used
M 8265
Not used Not used Not used
M 8266
Not used Not used Not used
M 8267
Not used Not used Not used
M 8268
Not used Not used Not used
M 8269
Not used Not used Not used
2nd analog special adapter
M 8270 Temperature unit selection Temperature unit selection Temperature unit selection
M 8271
Not used Type-K/-J switching Input sensor selection
M 8272
Not used Not used Not used
M 8273
Not used Not used Not used
M 8274
Not used Not used Not used
M 8275
Not used Not used Not used
M 8276
Not used Not used Not used
M 8277
Not used Not used Not used
M 8278
Not used Not used Not used
M 8279
Not used Not used Not used
3rd analog special adapter
M 8280 Temperature unit selection Temperature unit selection Temperature unit selection
M 8281
Not used Type-K/-J switching Input sensor selection
M 8282
Not used Not used Not used
M 8283
Not used Not used Not used
M 8284
Not used Not used Not used
M 8285
Not used Not used Not used
M 8286
Not used Not used Not used
M 8287
Not used Not used Not used
M 8288
Not used Not used Not used
M 8289
Not used Not used Not used
4th analog special adapter
M 8290 Temperature unit selection Temperature unit selection Temperature unit selection
M 8291
Not used Type-K/-J switching Input sensor selection
M 8292
Not used Not used Not used
M 8293
Not used Not used Not used
M 8294
Not used Not used Not used
M 8295
Not used Not used Not used
M 8296
Not used Not used Not used
M 8297
Not used Not used Not used
M 8298
Not used Not used Not used
M 8299
Not used Not used Not used
