FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
124
6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
6.8.5 [E] Special extension devices
1. Special function blocks
*1. When the voltage of the external DC power supply is 24V DC and 5V DC, the current is 70 mA and
100 mA, respectively.
*2. This master cannot be used together with FX2N-16CCL-M and/or FX2N-32ASI-M.
The following number of points is added according to the products connected to the network.
Number of remote I/O stations × 32 points
*3. This master cannot be used together with FX3U-16CCL-M and/or FX2N-32ASI-M.
The following number of points is added according to the products connected to the network.
Number of remote I/O stations × 32 points
*4. The following number of points is added according to the products connected to the network.
Total number of input/output points of remote I/O stations
*5. The number of points varies according to the products connected to the network.
For details, refer to FX2N-16LNK-M Manual.
*6. This master cannot be used together with FX3U-16CCL-M and/or FX2N-16CCL-M. Only one unit can
be added to the whole system.
The following number of points is added according to the products connected to the network.
Number of active slaves × 8 points
No. Type
Number of
input/occupied
output points
Current consumed (mA) Current
supply at
startup [mA]
*8
5V DC Internal 24V DC External 24V DC
FX3U-4AD 8 110 0 90 −
FX3U-4DA 8 120 0 160 −
FX3U-4LC 8 160 0 50 −
FX3U-2HC 8 245 0 0 −
FX3U-20SSC-H 8 100 0 220 −
FX3U-16CCL-M
8
*2
00 240 −
FX3U-64CCL 8 0 0 220 −
FX2N-2AD 8 20
50
*7
0170
FX2N-2DA 8 30
85
*7
0190
FX2N-4AD 8 30 0 55 −
FX2N-4DA 8 30 0 200 −
FX2N-4AD-TC 8 30 0 50 −
FX2N-4AD-PT 8 30 0 50 −
FX2N-8AD 8 50 0 80 −
FX2N-5A 8 70 0 90 −
FX2N-2LC 8 70 0 55 −
FX2N-1HC 8 90 0 0 −
FX2N-1PG(-E) 8 55 0 40 −
FX2N-10PG 8 120 0
70
*1
−
FX2N-232IF 8 40 0 80 −
FX2N-16CCL-M
8
*3
00 150 −
FX2N-32CCL 8 130 0 50 −
FX2N-64CL-M
8
*4
190
Supplied from power supply for
CC-Link/LT
−
FX
2N-16LNK-M
0
*5
200 0 90 −
FX2N-32ASI-M
8
*6
150 0 70 −
FX0N-3A 8 30
90
*7
0165
E
E1
E2
E3
