16.8.3 External dimensions
FX2N-8EYR-ES/UL
FX2N-8EYR-S-ES/UL
FX2N-16EYR-ES/UL
FX2N-8EYR-ES
POWER
0 1 23
7654
43(1.7")
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
Unit:mm (inches)
9(0.36")
2-φ4.5 mounting holes
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
9(0.36")
40(1.58")
2-φ4.5 mounting holes
Unit:mm (inches)
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
Unit:mm (inches)
9(0.36")
40(1.58")
2-φ4.5 mounting holes
