382

FX3U Series Programmable Controllers

User’s Manual - Hardware Edition

19 FX3U-7DM (Display Module)

19.1 Description of Products (Introduction of Related Products)

The FX3U-7DM display module can be incorporated in the main unit, or can be installed in the enclosure using

the FX3U-7DM-HLD display module holder.

For a detailed description of the display module holder, refer to the "FX3U-7DM-HLD User’s Manual".

Optional

Installation on main unit:

The display module can be

incorporated into the main unit.

Display module

-7DM

Display module holder

-7DM-HLD

Extension cable

(Supplied with FX

-7DM-HLD)

PLC

Installation in enclosure:

The FX

-7DM display module can be installed and used on

an outside panel.
