FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
366
18 Other Extension Devices and Optional Units (External Dimensions and Terminal Arrangement)
18.1 Special Function Units/Blocks
18.1.21 FX2N-1RM(-E)-SET
External Dimensions
•MASS(Weight): 0.5kg (1.1lbs)
•Installation: 35mm (1.38") wide DIN rail
or screws
•Accessories: FX2N-RS-5CAB signal cable
(5m(16’4")), F2-720RSV
resolver, extension cable
(55mm(2.06")), label for
indication of special unit/
block number, Manual
supplied with product
•Terminal block: M3 screws
Terminal Layout
55(2.17")
97(3.82")
80(3.15")
(mounting hole pitch)
90(3.55")
21
(0.83")
111(4.38")
Unit:mm (inches)
4
(0.16")
30
(1.19")
9
(0.36")
50
(1.97")
2-φ4.5 mounting holes
FX2N-1RM
10
(0.4")
3
4514
Unit:mm (inches)
9.5(0.38")
28
(1.11")
60
(2.37")
45(1.78")
4-φ4.5 mounting holes
φ33.32
φ10
φ40
φ50
9.5
(0.38")
45(1.78")
(0.12")
4
(0.16")
(1.78")(0.56")
B0
S/S 24+ 24-
B1
