FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
361
18 Other Extension Devices and Optional Units (External Dimensions and Terminal Arrangement)
18.1 Special Function Units/Blocks
11
High-Speed
Counters
12
Output Wiring
13
Wiring for
Various Uses
14
Test Run,
Maintenance,
Troubleshooting
15
IInput/Output
Powered
Extension Units
16
Input/Output
Extension
Blocks
17
Extension
Power Supply
Unit
18
Other Extension
Units and
Options
19
Display Module
20
Terminal Block
18.1.11 FX3U-4LC
External Dimensions
•MASS(Weight): 0.4kg (0.88lbs)
•Installation: 35mm (1.38") wide DIN rail
or screws
•Accessories: Label for indication of special
unit/block number,
Dust proof sheet,
Manual supplied with product
•Terminal block: M3 screws
•The extension cable is already connected to
the extension block
Terminal Layout
18.1.12 FX2N-2LC
External Dimensions
•MASS(Weight): 0.3kg (0.66lbs)
•Installation: 35mm (1.38") wide DIN rail
or screws
•Accessories: Label for indication of special
unit/block number,
Manual supplied with product
•Terminal block: M3 screws
•The extension cable is already connected to
the extension block
Terminal Layout
Unit:mm (inches)
2-φ4.5 mounting holes
82(3.23")
(mounting hole pitch)
90(3.55")
86(3.39")
9(0.36")
82(3.23")
(mounting hole pitch)
90(3.55")
24+ 24-
CT FG
CT
CT
FG
CT
OUT1 OUT2
COM1
OUT3
OUT4
CT FG
CT FG
CT
CT
COM2
CH1 CH2
CH3 CH4
PTB/TC-/COM
PTB/TC-/COM
PTA/ /
PTB/TC+/VL+
PTA/ /
PTB/TC+/VL+
PTB/TC-/COM
PTB/TC-/COM
PTA/ /
PTA/ /
PTB/TC+/VL+
PTB/TC+/VL+
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
Unit:mm (inches)
4(0.16")
9(0.36")
55(2.17")
2-φ4.5 mounting holes
24+
24-
OUT1OUT2
COM
CT FG
PTA
CT
CT FG
CH1
CT
PTB
TC-
PTB
TC+
PTA
PTB
TC-
PTB
TC+
CH2
