FX3U Series Programmable Controllers

User’s Manual - Hardware Edition

320

16 FX2N-8/16E*-*(Input/Output Extension Blocks)

16.2 FX2N-8ER-ES/UL (24V DC Sink/Source Input, Relay Output)

16.2.3 External dimensions

FX2N-8ER-ES

POWER

3210

OUT

43(1.7")

9(0.36")

80(3.15")

(mounting hole pitch)

87(3.43")

90(3.55")

Unit:mm(inches)2-φ4.5 mounting holes
