FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
50
3 Introduction of Products (Compliant with Overseas Standards)
3.2 Connector Types and Cables for Program Communication
3.2.1 Programming tool
The following programming tool supports FX3U Series PLCs.
→ For more information, refer to Chapter 5 "Version Information and Peripheral Equipment
Connectability".
3.2.2 Communication cables
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
Model name Description
GX Works2
Version 1.07H or later of SWDNC-GXW2-J supports the FX3U.
Version 1.08J or later of SWDNC-GXW2-E supports the FX3U.
GX Developer
Version 8.23Z or later of SWD5C-GPPW-J supports the FX3U.
Version 8.24A or later of SWD5C-GPPW-E supports the FX3U.
Although versions earlier than 8.23Z(-J) or 8.24A(-E) can be used for programming by
selecting the model "FX3U(C)" or "FX2N(C)", restrictions apply.
FX-30P FX-30P supports from the first version.
Model name Description
CE
UL
cUL
Marine
EMC LVD
USB cable
USB cable
3m
(9’10")
USB A plug  USB MINI B plug
For connection between personal computer and
FX3U-USB-BD
USB cable (3m(9’10")) supplied with FX3U-USB-BD or
commercially available cable (up to 5m(16’4"))
− − − −
RS-232C cable
F2-232CAB-1
3m
(9’10")
D-SUB 9Pin  D-SUB 25Pin
For connection between personal computer and
RS-232C/RS-422 converter
− − − −
F2-232CAB
3m
(9’10")
D-SUB 25Pin  D-SUB 25Pin
For connection between personal computer and
RS-232C/RS-422 converter
− − − −
F2-232CAB-2
3m
(9’10")
Half-pitch 14-pin D-SUB 25Pin
For connection between personal computer and
RS-232C/RS-422 converter
− − − −
FX-232CAB-1
3m
(9’10")
D-SUB 9Pin  D-SUB 9Pin
For connection between personal computer and FX
3U-
232-BD, FX3U-232ADP(-MB)
− − − −
FX-232CAB-2
3m
(9’10")
Half-pitch14Pin  D-SUB 9Pin
For connection between personal computer and FX3U-
232-BD, FX3U-232ADP(-MB)
− − − −
RS-422 cable
FX-422CAB0
1.5m
(4’11")
D-SUB 25Pin  MINI DIN 8Pin
For connection between RS-232C/RS-422 converter and
FX
3U programming port FX3U-422-BD
− − − −
1
2
3
4
3
1
1
1
4
4
2
