FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
46
3 Introduction of Products (Compliant with Overseas Standards)
3.1 List of Products (to be Connected) and Interpretation of Model Names
3.1.7 [H] Special adapters
1. Analog functions
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
*1. Products manufactured in and after June, 2005 will comply with the overseas standard.
*2. Please consult with Mitsubishi Electric for information on marine standard practices and the
corresponding types of equipment.
→ For more information on CE, UL and cUL, refer to Page 15 or later.
2. Communication functions
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
*1. Products manufactured in and after June, 2005 will comply with the overseas standard.
*2. Please consult with Mitsubishi Electric for information on marine standard practices and the
corresponding types of equipment.
→ For more information on CE, UL and cUL, refer to Page 15 or later.
3. CF card functions
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
→ For more information on CE, UL and cUL, refer to Page 15 or later.
Model name Description
CE
UL
cUL
Marine
EMC LVD
FX3U-4AD-ADP 4-ch voltage input/current input

*1
îš…

*1
*2
FX3U-4DA-ADP 4-ch voltage output/current output

*1
îš…

*1
*2
FX3U-3A-ADP
2-ch voltage input/current input
1-ch voltage output/current output
 −
FX
3U-4AD-PT-ADP 4-ch platinum resistance thermometer sensor input

*1
îš…

*1
*2
FX3U-4AD-PTW-ADP
4-ch platinum resistance thermometer sensor input
(-100 to 600°C)
 −
FX
3U-4AD-PNK-ADP
4-ch temperature sensor input
(Pt1000/Ni1000 resistance thermometer sensor) input
 −
FX
3U-4AD-TC-ADP 4-ch thermocouple (K, J type) temperature sensor input

*1
îš…

*1
*2
Model name Description
CE
UL
cUL
Marine
EMC LVD
FX3U-232ADP-MB RS-232C communication *2
FX3U-485ADP-MB RS-485 communication *2
FX3U-232ADP RS-232C communication

*1
îš…

*1
*2
FX3U-485ADP RS-485 communication

*1
îš…

*1
*2
Model name Description
CE
UL
cUL
Marine
EMC LVD
FX
3U-CF-ADP CF card special adapter  −
H
H
H
