Mitsubishi FX3U-4HSX-ADP User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
125
6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
*7. When analog special function blocks (FX0N-3A, FX2N-2AD and FX2N-2DA) are connected to an input/
output powered extension unit (FX2N-32E or FX2N-48E), the following limitation must be taken into
consideration. (When the blocks are connected to the main unit, this limitation is not applied.)
The total current consumption of the analog special function blocks (FX0N-3A, FX2N-2AD and FX2N-
2DA) should be less than the following current values.
- Total current consumption of blocks connected to FX2N-32E: 190 mA or less
- Total current consumption of blocks connected to FX2N-48E: 300 mA or less
*8. When applying the DC power type main unit, calculate the current consumption at startup.
2. Special function units
6.8.6 [G] Display module
−: No need to calculate
6.8.7 [H] Extension power supply unit
−: No need to calculate
*1. The ambient temperature restricts the output current. For details, refer to the derating curve in Section
6.7.
No. Type
Number of input/
occupied output
points
Current consumed (mA)
5V DC Internal 24V DC External 24V DC
FX2N-10GM 8
− − 5
FX2N-20GM 8
− − 10
FX2N-1RM(-E)-SET 8
− − 5
No. Type
Number of input/
occupied output
points
Current consumed (mA)
5V DC Internal 24V DC External 24V DC
FX3U-7DM
− 20 0 0
No. Type
Number of input/
occupied output
points
Current consumed (mA)
*1
5V DC Internal 24V DC
FX3U-1PSU-5V
− 1000 300
E
E3
G
G1
H
H1
