FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
120
6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
6.8.1 [A] Main units
No. Type
Input/output Output current (mA)
Number of input/
output points
[points]
Input/output
[points]
5V DC power
supply
24V DC service power
supply
AC power supply/24V DC input/relay output type
FX3U-16MR/ES 16 8/8
500
400
FX3U-32MR/ES 32 16/16
FX3U-48MR/ES 48 24/24
600
FX3U-64MR/ES 64 32/32
FX3U-80MR/ES 80 40/40
FX3U-128MR/ES 128 64/64
AC power supply/24V DC input/transistor output type
FX3U-16MT/ES 16 8/8
500
400
FX3U-16MT/ESS 16 8/8
FX3U-32MT/ES 32 16/16
FX3U-32MT/ESS 32 16/16
FX3U-48MT/ES 48 24/24
600
FX3U-48MT/ESS 48 24/24
FX3U-64MT/ES 64 32/32
FX3U-64MT/ESS 64 32/32
FX3U-80MT/ES 80 40/40
FX3U-80MT/ESS 80 40/40
FX3U-128MT/ES 128 64/64
FX3U-128MT/ESS 128 64/64
AC power supply/24V DC input/triac output type
FX3U-32MS/ES 32 16/16
500
400
FX3U-64MS/ES 64 32/32 600
No. Type
Input/output Output current (mA)
Number of input/
output points
[points]
Input/output
[points]
5V DC power
supply
24V DC service power
supply
AC power supply/100V AC input/relay output type
FX3U-32MR/UA1 32 16/16
500
400
FX3U-64MR/UA1 64 32/32 600
A
A1
A1
A1
A2
